6ES7972-0AB01-0XA0 Diagnostic Repeater for PROFIBUS DP

Part number

6ES7972-0AB01-0XA0

Brand

Siemens

Category

Communication & Networking

Product type

Diagnostic repeater for PROFIBUS DP

Lifecycle

Phase Out Announce

Dimensions

13.5 x 10.1 x 7.5 cm

Net weight

0.325 Kg

Source category

Diagnostic repeater for PROFIBUS DP

• This component functions as a diagnostic repeater tailored for PROFIBUS DP applications in industrial settings. Keep dimensions 13.5 x 10.1 x 7.5 cm and net weight 0.325 Kg unchanged while comparing project documents and product image evidence.
• It provides capabilities for online diagnostics of the PROFIBUS cable to identify potential network issues.
• The device supports connection to DP standard slaves with data transfer rates reaching up to 12 Mbit/s.
• Physical protection is rated at IP20, ensuring basic protection against solid objects and fingers.
• Connections utilize the FastConnect method, allowing for quick and secure wiring installation procedures.
• The unit operates within the broader SIMATIC S7 ecosystem for integrated automation solutions.

• The manufacturer brand associated with this part number is Siemens, a recognized leader in automation. Use the source path Automation technology / Diagnostics / Diagnostic repeater for PROFIBUS DP to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• The specific product type is identified as a diagnostic repeater for PROFIBUS DP networks.
• Lifecycle status is recorded as Phase Out Announce, indicating future discontinuation planning by the maker.
• The normalized part number format removes hyphens for consistent database matching and search operations.

Parameters are factual source fields retained for model review.

• Physical dimensions are listed as 13.5 x 10.1 x 7.5 cm for spatial planning purposes. Check product-owned images, label text, connector area, and submitted model references against the exact 6ES7972-0AB01-0XA0 record before publication.
• Net weight is recorded at 0.325 Kg, which assists in logistics and mounting calculations.
• The degree of protection is specified as IP20, defining its resistance to environmental factors.
• Connection methodology employs FastConnect, streamlining the assembly process for electrical wiring connections.
• Maximum supported baud rate for connected slaves is 12 Mbit/s for high-speed communication.
