Siemens 6ES7223-1QH32-0XB0 Digital Input/Output Module Inquiry

Part number

6ES7223-1QH32-0XB0

Brand

Siemens

Category

I/O Modules

Product type

SM 1223 digital input/output modules

Lifecycle

Active Product

Dimensions

10.1 x 8.8 x 5.6 cm

Net weight

0.223 Kg

Source category

SM 1223 digital input/output modules

• The device belongs to the SM 1223 digital input/output module product class within the Siemens portfolio. Keep dimensions 10.1 x 8.8 x 5.6 cm and net weight 0.223 Kg unchanged while comparing project documents and product image evidence.
• It incorporates eight digital inputs configured for alternating current signals at standard industrial voltage levels.
• The output configuration consists of eight relay-based digital outputs for switching electrical circuits.
• Each digital output channel is rated for a maximum current capacity of 2 amperes.
• The physical dimensions of the module are recorded as 10.1 cm by 8.8 cm by 5.6 cm.
• The net weight of the unit is listed as 0.223 kilograms for logistical planning purposes.

• The specific part number for this digital I/O module is 6ES7223-1QH32-0XB0. Use the source path Automation technology / Digital modules / SM 1223 digital input/output modules to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• The normalized identifier for database matching is 6ES72231QH320XB0 without hyphens.
• The manufacturer brand associated with this component is Siemens Industrial Automation.
• The product lifecycle status is currently classified as Active Product for ongoing support.

Parameters are factual source fields retained for model review.

• Input type is specified as digital with support for AC voltage signal processing. Check product-owned images, label text, connector area, and submitted model references against the exact 6ES7223-1QH32-0XB0 record before publication.
• Output type is defined as digital utilizing relay switching mechanisms for isolation.
• Input voltage range covers standard 120 V and 230 V AC supply networks.
• Output current rating per channel is fixed at 2 A for resistive loads.
• Module form factor fits standard DIN rail mounting within S7-1200 rack systems.

• Visual inspection should confirm the presence of eight input terminal connections on the left.
• Check that eight output terminal blocks are visible on the right side of the unit.
• Verify the label displays the full part number 6ES7223-1QH32-0XB0 clearly and legibly.
• Ensure the front cover shows no signs of physical damage or connector corrosion.

• Review your project documentation to confirm the required number of digital input channels.
• Verify that your control system uses the SIMATIC S7-1200 CPU architecture for integration.
• Check that your field devices operate within the 120/230 V AC input voltage range.
• Confirm that load currents do not exceed the 2 A relay output specification limits.

• Cross-reference the part number with your existing bill of materials for accuracy.
• Validate the voltage requirements of your sensors against the module input specifications.
• Assess the switching capacity of your actuators against the module output ratings.
• Consult technical manuals for detailed wiring diagrams and installation guidelines before request.
