Siemens 6ES7223-1BL32-1XB0 Digital Input/Output Module Inquiry

Part number

6ES7223-1BL32-1XB0

Brand

Siemens

Category

I/O Modules

Product type

SM 1223 digital input/output modules

Lifecycle

Active Product

Dimensions

10.9 x 8.8 x 8.5 cm

Net weight

0.286 Kg

Source category

SM 1223 digital input/output modules

• The module operates with sixteen digital inputs rated at 24 V DC voltage levels for standard industrial signaling.
• Input circuitry supports both sourcing and sinking configurations to accommodate different sensor types and wiring schemes.
• Sixteen digital outputs utilize NPN transistor technology capable of delivering up to 0.5 A per channel.
• Output configuration is set to sourcing mode, allowing connection to loads that require a common positive supply.
• Physical dimensions are recorded as 10.9 cm in width, 8.8 cm in height, and 8.5 cm in depth.
• The net weight of the unit is listed as 0.286 kg, indicating a compact form factor for DIN rail mounting.

• Identify the product by the full part number 6ES7223-1BL32-1XB0 when referencing this specific hardware variant.
• The normalized identifier 6ES72231BL321XB0 removes hyphens for database indexing and systematic classification purposes.
• This item belongs to the SM 1223 digital input/output modules product class within the broader catalog.
• Current lifecycle status is documented as Active Product, indicating ongoing production and support review details.
