6ES7146-6FF00-0AB0 SIMATIC ET 200eco PN Fail-Safe I/O Device

Part number

6ES7146-6FF00-0AB0

Brand

Siemens

Category

I/O Modules

Product type

Fail-safe I/O device

Lifecycle

Active Product

Dimensions

22.1 x 7.00 x 6.00 cm

Net weight

0.995 Kg

Source category

Fail-safe I/O device

• This module features eight digital inputs operating at 24 V DC for safety signal processing. Keep dimensions 22.1 x 7.00 x 6.00 cm and net weight 0.995 Kg unchanged while comparing project documents and product image evidence.
• Three digital outputs are provided, each capable of delivering 2 A at 24 V DC.
• Communication utilizes M12 PROFIsafe connectors to ensure secure data transmission in safety loops.
• The device achieves Performance Level e according to ISO 13849 standards for risk reduction.
• Safety Integrity Level 3 compliance is recorded under IEC 61508 for functional safety.
• Enclosure protection is rated IP65 and IP67 against dust ingress and water jets.

• The part number 6ES7146-6FF00-0AB0 identifies the specific hardware configuration for this unit. Use the source path Automation technology / SIMATIC ET 200eco PN / I/O devices / Fail-safe I/O device to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• Normalized identifier 6ES71466FF000AB0 is used for database indexing and reference tracking purposes.
• Brand attribution links this component to Siemens within the broader automation technology sector.
• Lifecycle status is listed as Active Product, indicating ongoing manufacturing or support review details.

Parameters are factual source fields retained for model review.

• Physical dimensions are recorded as 22.1 cm in length, 7.00 cm in width, and 6.00 cm in height. Check product-owned images, label text, connector area, and submitted model references against the exact 6ES7146-6FF00-0AB0 record before publication.
• Net weight is specified at 0.995 Kg for logistics planning and mounting considerations.
• Input channel count is fixed at eight digital points for standard safety interface needs.
• Output channel capacity consists of three digital points with defined current ratings per channel.
• Connector type is standardized as M12 to facilitate quick wiring and robust connections.

• Visual inspection should confirm the presence of M12 connector ports on the front face.
• Labeling must display the full part number 6ES7146-6FF00-0AB0 for accurate identification.
• Housing integrity should show no visible damage to maintain IP65/67 protection ratings.
• Mounting rails and clip mechanisms appear designed for DIN rail installation in panels.

• Review project documents to verify voltage requirements match the 24 V DC specification.
• Confirm that the control system supports PROFIsafe protocol for safe communication integration.
• Check physical space constraints against the 22.1 x 7.00 x 6.00 cm dimensions.
• Validate safety level requirements align with the recorded PL e and SIL 3 capabilities.

• Source parameter review confirms the active product status for this Siemens component.
• Project document review should address integration with existing ET 200eco PN networks.
• Technical specification analysis highlights the importance of M12 PROFIsafe connectivity for safety.
• Dimensional verification ensures proper fit within control cabinet layouts and mounting structures.
