Siemens 6ES7142-6BR00-0BB0 Digital I/O Device Inquiry

Part number

6ES7142-6BR00-0BB0

Brand

Siemens

Category

I/O Modules

Product type

Digital I/O devices

Lifecycle

Active Product

Dimensions

22.4 x 6.00 x 5.5 cm

Net weight

0.814 Kg

Source category

Digital I/O devices

• Eight digital output channels switch 24 V DC loads at up to 2 A each. Keep dimensions 22.4 x 6.00 x 5.5 cm and net weight 0.814 Kg unchanged while comparing project documents and product image evidence.
• M12 connectors allow flexible wiring with single or double assignment options for field devices.
• Source output configuration uses PNP switching logic connecting loads to positive potential.
• Channel diagnostics monitor wire breaks and short circuits at the output terminals directly.
• Isochronous mode operates at 0.25 ms intervals for precise synchronized control tasks.
• Prioritized startup and MSO features support efficient system initialization and maintenance operations.

• Brand designation is Siemens, belonging to the broader SIMATIC automation product family. Use the source path Automation technology / SIMATIC ET 200eco PN / I/O devices / Digital I/O devices to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• Product line is identified as SIMATIC ET 200eco PN distributed I/O system.
• Device class is Digital I/O devices, specifically focusing on digital output functions.
• Lifecycle status is recorded as Active Product, indicating current manufacturing and support.

Parameters are factual source fields retained for model review.

• Physical dimensions are listed as 22.4 cm length, 6.00 cm width, and 5.5 cm height. Check product-owned images, label text, connector area, and submitted model references against the exact 6ES7142-6BR00-0BB0 record before publication.
• Net weight is documented at 0.814 Kg for logistics and mounting calculations.
• Degree of protection is rated IP67 and IP69K for harsh industrial environments.
• Multi-fieldbus support includes PN IO, Ethernet/IP, and Modbus TCP protocols.
• Redundancy features include S2 redundancy and shared device capability with two controllers.

• Visual inspection should confirm the presence of eight M12 connector ports on the front. Review Siemens 6ES7142-6BR00-0BB0 as Digital I/O devices with source category Digital I/O devices, recorded lifecycle Active Product, and submitted model identity.
• Labeling must clearly display the full part number 6ES7142-6BR00-0BB0 without obstructions.
• Connector orientation and locking mechanisms should be visible for installation verification.
• Housing integrity and mounting rail interface need clear depiction for structural review.

• Verify the required voltage level matches the 24 V DC specification of this module. Keep dimensions 22.4 x 6.00 x 5.5 cm and net weight 0.814 Kg unchanged while comparing project documents and product image evidence.
• Confirm that the load current does not exceed the 2 A per channel limit.
• Check if M12 connector types align with existing field device cable assemblies.
• Ensure the control system supports the necessary PROFINET or Ethernet/IP protocols.

• Cross-reference the part number with project documentation to ensure exact model match.
• Review technical datasheets for detailed electrical characteristics and timing diagrams.
• Consult installation guidelines for proper mounting and wiring procedures in IP67 enclosures.
• Validate redundancy requirements against the shared device and S2 redundancy capabilities.
