Siemens 6AV7674-1LB20-0AA0 Label Holder for Operator Controls

Part number

6AV7674-1LB20-0AA0

Brand

Siemens

Category

HMI Panels

Product type

Extension Units and operator controls

Lifecycle

Active Product

Dimensions

15.9 x 11.6 x 2.4 cm

Net weight

0.039 Kg

Source category

Extension Units and operator controls

• The physical dimensions are recorded as 15.9 cm in length, 11.6 cm in width, and 2.4 cm in height for each individual unit.
• The net weight is listed at 0.039 kg per piece, indicating a lightweight construction listed for easy handling during installation processes.
• The product lifecycle status is currently active, meaning it remains a standard product within the manufacturer's current portfolio offerings.
• Labeling plates measure 16.05 mm by 26.3 mm, providing adequate space for necessary text or codes on the operator control surfaces.
• The scope of supply includes twelve label holders along with twelve matching transparent covers to protect the inscribed information from wear.
• Installation involves gluing the holders directly onto the designated areas of the operator controls for secure attachment and stability.

• Identify this part by the full alphanumeric code 6AV7674-1LB20-0AA0 found on all documentation and packaging materials.
• The normalized part number appears as 6AV76741LB200AA0 without hyphens, useful for database searches and inventory management systems.
• Class A classification indicates this is a standard product that may be subject to specific review guidelines if applicable.
• It is categorized under PROtected devices and system components, specifically within the Extension Units and operator controls sub-section.

Parameters are factual source fields retained for model review.

• Verify the labeling plate size requirement matches the 16.05 mm x 26.3 mm specification before proceeding with any inquiries.
• Confirm that the gluing method aligns with your facility's assembly protocols for attaching labels to operator control panels.
• Check if the template for labeling download is accessible, as it provides guidance for proper inscription formatting and placement.
• Ensure the application does not involve EMERGENCY STOP buttons, as this product is explicitly not listed for that specific use case.
• Review the quantity requirements to determine if the standard pack of twelve holders meets your project's total labeling needs.

• Images typically show the flat, rectangular shape of the label holder with its distinctively rounded bottom edge design.
