Siemens 6AV3688-3XY38-3AX0 Design Empty Front Panel

Part number

6AV3688-3XY38-3AX0

Brand

Siemens

Category

HMI Panels

Product type

design empty front in KP8 format for easy mounting of standard 22

Lifecycle

Active Product

Dimensions

18.2 x 10.8 x 6.2 cm

Net weight

0.31 Kg

Source category

SIMATIC HMI KP8/KP8F/KP32F

• The part number 6AV3688-3XY38-3AX0 identifies this specific Siemens component. Keep dimensions 18.2 x 10.8 x 6.2 cm and net weight 0.31 Kg unchanged while comparing project documents and product image evidence.
• It is classified under the Basic HMI category within automation technology.
• The physical dimensions are recorded as 18.2 x 10.8 x 6.2 cm.
• Net weight is listed at 0.31 Kg for logistical planning purposes.
• The lifecycle status is noted as Active Product in current records.
• It falls under the SIMATIC HMI KP8/KP8F/KP32F product family line.

• Verify the full alphanumeric code 6AV3688-3XY38-3AX0 during submission. Use the source path Automation technology / Basic HMI / Key Panels / SIMATIC HMI KP8/KP8F/KP32F to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• Confirm the normalized identifier 6AV36883XY383AX0 matches project documentation.
• Check that the brand designation aligns with Siemens manufacturing standards.
• Ensure the KP8 format specification meets your mechanical requirements.
