6AV2128-3XB57-0BX0 SIMATIC HMI MTP2200 PRO Panel Details

Part number

6AV2128-3XB57-0BX0

Brand

Siemens

Category

HMI Panels

Product type

SIMATIC HMI MTP2200 PRO, for support arm (expandable, round pipe) and Extension Unit, neutral front, 21

Lifecycle

Active Product

Dimensions

62.00 x 39.00 x 15.00 cm

Net weight

9.88 Kg

Source category

SIMATIC HMI Unified Comfort Panel PRO

• Display technology utilizes a 21.5-inch widescreen TFT panel providing high-resolution visual output for operator interaction.
• Color depth is specified at 16 million colors, ensuring detailed graphical representation of process data on the screen.
• Connectivity relies on a PROFINET interface, enabling robust communication within industrial Ethernet networks for real-time data exchange.
• Software configuration requires WinCC Unified Comfort V18 or later versions to fully utilize the panel's operational capabilities.
• The unit incorporates open-source software components, which are provided free of charge as part of the standard package.
• Physical construction supports mounting on expandable round pipe support arms and connects directly to extension units.

• The part number 6AV2128-3XB57-0BX0 identifies this specific variant within the SIMATIC HMI Unified Comfort Panel PRO series.
• Model designation MTP2200 PRO indicates the product line focused on machine tool panel applications with enhanced features.
• The suffix PRO denotes professional-grade hardware designed for demanding industrial environments requiring high reliability and performance.
• Neutral front designation implies a standardized bezel design without integrated branding or specific application markings.

Parameters are factual source fields retained for model review.

• Overall dimensions are recorded as 62.00 cm in width, 39.00 cm in height, and 15.00 cm in depth.
• Net weight is listed at 9.88 kilograms, reflecting the substantial build quality required for industrial automation tasks.
• Lifecycle status is currently active, indicating ongoing production and support for this specific hardware configuration.
• Category classification places this unit under SIMATIC HMI Unified Comfort Panels, specifically the PRO sub-category.
• Screen size measurement confirms a 21.5-inch diagonal display area, optimized for comprehensive data visualization needs.

• Visual documentation should highlight the neutral front panel design characteristic of this specific MTP2200 PRO model.
