Siemens 6AG2516-3FN02-2AB0 Central Processing Unit Inquiry

Part number

6AG2516-3FN02-2AB0

Brand

Siemens

Category

Cables, Connectors & Accessories

Product type

Cables, Connectors & Accessories

Lifecycle

Prod. Cancellation

Dimensions

15.4 x 15.1 x 4.6 cm

Net weight

0.916 Kg

• Memory configuration includes 1.5 MB for program storage and 5 MB for data retention within the central processing unit architecture. Keep dimensions 15.4 x 15.1 x 4.6 cm and net weight 0.916 Kg unchanged while comparing project documents and product image evidence.
• The first interface utilizes PROFINET IRT technology equipped with a two-port switch for high-speed network communication capabilities.
• A second PROFINET RT interface provides additional real-time networking options for distributed automation tasks and control loops.
• The third interface supports PROFIBUS communication, enabling integration with legacy devices and fieldbus networks in industrial settings.
• Bit performance is recorded at 10 nanoseconds, ensuring rapid processing speeds for complex logic and motion control applications.
• Operating temperature tolerance extends to OT2 standards, allowing temporary peaks up to 70 degrees Celsius for ten minutes.

• The part number 6AG2516-3FN02-2AB0 identifies the SIPLUS variant of the S7-1500 CPU 1516F-3 PN/DP.
• This model is based on the hardware foundation of the 6ES7516-3FN02-0AB0 central processing unit component.
• The SIPLUS designation indicates specific enhancements for extreme environmental conditions compared to standard industrial automation components.
• Lifecycle status is currently listed as Prod. Cancellation, indicating the end of production for this specific item.

Parameters are factual source fields retained for model review.

• Physical dimensions are recorded as 15.4 cm in length, 15.1 cm in width, and 4.6 cm in height.
• Net weight is listed at 0.916 kilograms, which is relevant for mounting and logistics planning considerations.
• A SIMATIC Memory Card is required for operation, serving as essential storage for program and data files.
• The unit supports fail-safe functions, indicated by the F designation within the CPU model classification structure.
• Interface types include both PROFINET and PROFIBUS, offering versatile connectivity options for modern industrial network architectures.

• Images typically display the front panel with terminal blocks and status indicator lights for operational monitoring.
• Labeling on the device confirms the full part number and brand identity for verification during source review.
• Rail mounting clips are visible, showing how the unit attaches to standard DIN rails in control cabinets.
• Connector ports for PROFINET and PROFIBUS are clearly positioned on the front face for cable access.

• Review project documents to confirm that the extended temperature range meets your specific environmental requirements.
• Verify that your network infrastructure supports PROFINET IRT and PROFIBUS protocols for proper interface utilization.
• Ensure that SIMATIC Memory Cards are included in your setup for necessary program and data storage.
• Check lifecycle status implications for long-term maintenance planning given the Prod. Cancellation classification.

• Confirm all interface requirements match your existing network topology before submitting detailed technical inquiries.
• Consider the environmental rating when selecting components for outdoor or harsh indoor industrial installations.
• Review the memory specifications to ensure they align with the complexity of your control programs.
• Note the cancellation status when planning for future scalability or system expansion projects.
