Siemens 6AG1314-6BH04-7AB0 CPU Module Specification Review

Part number

6AG1314-6BH04-7AB0

Brand

Siemens

Category

Cables, Connectors & Accessories

Product type

Cables, Connectors & Accessories

Lifecycle

Prod. Cancellation

Dimensions

13.00 x 15.00 x 1.00 cm

Net weight

0.768 Kg

• The central processing unit operates with a work memory capacity of 192 KB for program storage and execution tasks.
• Input configuration includes twenty-four digital inputs and sixteen digital outputs for direct device interfacing and control signals.
• Analog signal processing is handled by four analog inputs and two analog outputs for continuous variable monitoring.
• Temperature sensing capability is provided through one dedicated Pt100 input channel for precise thermal measurement integration.
• High-speed counting functions are supported via four counters operating at frequencies up to sixty kilohertz for rapid event tracking.
• Communication interfaces feature an integrated MPI port and an RS-485 interface for network connectivity and data exchange.

• The part number 6AG1314-6BH04-7AB0 identifies the specific SIPLUS variant based on the base model 6ES7314-6BH04-0AB0.
• Lifecycle status is recorded as Production Cancellation, indicating the end of standard manufacturing cycles for this specific SKU.
• Product class designation B notes that review are restricted and require direct contact with designated Siemens support channels.
• The normalized identifier 6AG13146BH047AB0 serves as the unformatted reference code for database indexing and search queries.

Parameters are factual source fields retained for model review.

• Physical dimensions are listed as thirteen centimeters by fifteen centimeters by one centimeter for spatial planning purposes.
• Net weight is recorded at zero point seven six eight kilograms, aiding in logistics and mounting load calculations.
• Power supply requirements specify an integrated twenty-four volt DC source for stable operational voltage delivery to the unit.
• Front connector specifications indicate a requirement for two forty-pole connectors to facilitate proper wiring and signal termination.
• Micro Memory Card usage is noted as a required component for additional data storage and configuration management tasks.

• Visual inspection should confirm the presence of conformal coating on internal circuitry visible through standard housing openings.
• Labeling must clearly display the full part number 6AG1314-6BH04-7AB0 along with Siemens branding and certification marks.
• Connector ports should be examined for integrity, ensuring no physical damage to the MPI and RS-485 interfaces.
• Mounting rails and clip mechanisms need verification to ensure secure attachment to standard DIN rail installations.

• Verify the exact quantity required for your project documentation to ensure accurate submission of the inquiry form.
• Confirm the operational environment temperature range matches the specified minus twenty-five to plus seventy degrees Celsius limit.
• Check if the required Micro Memory Card and front connectors are included in your existing inventory or inquiry preparation list.
• Review the review restriction policy associated with Product Class B before initiating any logistical or shipping arrangements.

• Ensure all technical parameters align with your specific application requirements before finalizing the inquiry submission process.
• Cross-reference the base model 6ES7314-6BH04-0AB0 to understand the foundational architecture underlying this specialized SIPLUS variant.
• Document the production cancellation status for long-term maintenance planning and potential future upgrade considerations.
• Validate the weight and dimension constraints against your installation space to confirm physical application context with existing setups.
