Siemens 6AG1244-0BB12-2BA1 SIPLUS SINAMICS G120 Control Unit Inquiry

Part number

6AG1244-0BB12-2BA1

Brand

Siemens

Category

Drives & Motion

Product type

Drives & Motion

Lifecycle

Active Product

Dimensions

199.00 x 46.00 x 73.00 mm

Net weight

0.554 Kg

Source category

SIPLUS Control Units

• Physical dimensions are recorded at 199.00 x 46.00 x 73.00 mm, providing a compact footprint for integration. Keep dimensions 199.00 x 46.00 x 73.00 mm and net weight 0.554 Kg unchanged while comparing project documents and product image evidence.
• The net weight is listed as 0.554 Kg, facilitating manageable handling during installation and maintenance procedures.
• Operating temperature range spans from -20 to +55 °C, ensuring functionality in varied thermal conditions.
• Communication relies on the USS protocol via RS-485 interface, supporting standard serial data exchange methods.
• Input and output capabilities include six digital inputs, three digital outputs, two analog inputs, and two analog outputs.
• Safety Integrated STO functionality is included, offering standard torque off protection for enhanced operational safety protocols.

• The base model derives from the 6SL3244-0BB12-1BA1 configuration, adapted for specific industrial environment requirements.
• SIPLUS branding indicates enhanced material and design standards for use in harsh or extreme operating conditions.
• The E-type designation specifies the particular hardware revision and feature set associated with this control unit.
• USS protocol support defines the primary communication method for parameterization and process data exchange with drives.

Parameters are factual source fields retained for model review.

• Conformal coating is applied to protect internal circuitry from moisture, dust, and corrosive atmospheric contaminants.
• The unit operates without an integrated power module, requiring connection to separate drive power components.
• Interface options include USB and SD/MMC slots for data logging, firmware updates, and configuration storage.
• Additional interface support includes a max. 1F-DI PTC/KTY connection for motor temperature monitoring integration.
• Degree of protection is rated IP20, indicating protection against solid objects larger than 12.5 mm.

• Visual inspection should confirm the presence of the Siemens branding and specific model number labeling.
• Check terminal block connections for integrity, ensuring no visible damage to communication or power ports.
• Verify the condition of the housing to ensure the conformal coating remains intact and undamaged.
• Confirm that all interface ports, including USB and SD/MMC, are accessible and free of debris.

• Review project documentation to confirm the required temperature range and environmental protection needs are met.
• Verify that the existing drive system supports the USS protocol for seamless communication integration.
• Assess space constraints to ensure the 199mm width fits within the designated control cabinet layout.
• Prepare technical questions regarding the specific application of Safety Integrated STO in your workflow.

• Ensure all technical specifications align with the specific operational requirements of the target machinery.
• Cross-reference the lifecycle status as Active Product to confirm ongoing support and documentation review details.
• Note the product class restriction regarding review, which requires direct contact with designated review contacts.
• Validate that the absence of a power module matches the system architecture of the intended installation.
