Inquiry for Siemens 6AG1231-5ND32-4XB0 Analog Input Module

Part number

6AG1231-5ND32-4XB0

Brand

Siemens

Category

I/O Modules

Product type

I/O Modules

Lifecycle

Active Product

Dimensions

11.00 x 8.8 x 5.7 cm

Net weight

0.169 Kg

Source category

SIPLUS SM 1231 analog input modules

• The device operates within an extended temperature range of -20°C to +60°C. This allows functionality in environments with significant thermal variations.
• Conformal coating protects internal components against moisture, dust, and corrosive agents. This enhancement ensures reliability in challenging industrial conditions.
• The module offers four analog input channels for signal processing. These channels support multiple standard industrial measurement types effectively.
• Input signal ranges include ±10 V, ±5 V, ±2.5 V, and ±1.25 V options. Current inputs support 0-20 mA and 4-20 mA standards.
• Resolution is specified at 15 bits plus a sign bit for accurate data representation. This precision supports detailed analysis of analog signals.
• Physical dimensions are recorded as 11.00 x 8.8 x 5.7 cm. The net weight is listed at 0.169 Kg for handling reference.

• The part number 6AG1231-5ND32-4XB0 identifies this specific SIPLUS variant. It distinguishes the ruggedized version from standard S7-1200 modules.
• This model belongs to the SM 1231 series of analog input modules. It is categorized under SIPLUS analog modules for automation technology.
• The lifecycle status is recorded as an Active Product. This indicates ongoing production and support for the component.
• The base design originates from the 6ES7231-5ND32-0XB0 module. Modifications include environmental protection features for extended operational use.
