Inquiry: Siemens 6AG1222-1HF32-4XB0 Digital Output Module

Part number

6AG1222-1HF32-4XB0

Brand

Siemens

Category

I/O Modules

Product type

I/O Modules

Lifecycle

Active Product

Dimensions

10.5 x 9.00 x 5.8 cm

Net weight

0.186 Kg

Source category

SIPLUS SM 1222 digital output modules

• The module delivers eight discrete digital output channels configured as relay switches for load control. Keep dimensions 10.5 x 9.00 x 5.8 cm and net weight 0.186 Kg unchanged while comparing project documents and product image evidence.
• Each output channel supports a maximum switching current of two amperes for reliable signal transmission.
• Conformal coating is applied to the circuit board to protect components from moisture and corrosion.
• The operating temperature range extends from negative twenty degrees Celsius to positive sixty degrees Celsius.
• Physical dimensions are recorded as ten point five centimeters in width by nine centimeters deep.
• Net weight is listed at zero point one eight six kilograms for structural planning purposes.

• This part number identifies the SIPLUS variant which differs from the standard S7-1200 series. Use the source path Automation technology / SIPLUS digital modules / SIPLUS SM 1222 digital output modules to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• The base model reference is 6ES7222-1HF32-0XB0 with specific modifications for harsh environment durability.
• SIPLUS designation indicates enhanced material selection and processing for extreme industrial conditions.
• Digital output configuration remains consistent with standard relay output behavior for general purpose switching.
