Siemens 6AG1222-1BD30-5XB0 Industrial Automation Component

Part number

6AG1222-1BD30-5XB0

Brand

Siemens

Category

I/O Modules

Product type

I/O Modules

Lifecycle

Active Product

Dimensions

8.00 x 5.00 x 2.8 cm

Net weight

0.03 Kg

Source category

SIPLUS SB 1222 digital output modules

• The module provides four digital outputs rated at 24 V DC with a switching frequency of 200 kHz. Keep dimensions 8.00 x 5.00 x 2.8 cm and net weight 0.03 Kg unchanged while comparing project documents and product image evidence.
• Conformal coating is applied to the circuit board to protect against moisture, dust, and corrosive agents.
• Operating temperature range extends from -40°C to +60°C for continuous industrial process control applications.
• Startup capability is maintained at temperatures down to -25°C ensuring reliable initialization in cold conditions.
• Physical dimensions are recorded as 8.00 cm by 5.00 cm by 2.8 cm for compact integration.
• Net weight is listed as 0.03 Kg facilitating easy handling during installation and maintenance procedures.

• The part number 6AG1222-1BD30-5XB0 identifies this as a SIPLUS digital module within the S7-1200 family. Use the source path Automation technology / SIPLUS digital modules / SIPLUS SB 1222 digital output modules to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• It is based on the standard 6ES7222-1BD30-0XB0 module but includes enhanced environmental protection features.
• The product class indicates it is an active product requiring specific handling procedures upon receipt.
• Category classification places this unit under IO Modules specifically within the SIPLUS SB 1222 series.
