Siemens 6AG1155-6AU00-7HM0 SIPLUS ET 200SP Interface Module Inquiry

Part number

6AG1155-6AU00-7HM0

Brand

Siemens

Category

I/O Modules

Product type

SIPLUS ET 200SP IM155-6PN R1 based on 6ES7155-6AU00-0HM0 with conformal coating -40

Lifecycle

Active Product

Dimensions

12.2 x 8.3 x 6.3 cm

Net weight

0.221 Kg

Source category

SIPLUS interface modules

• Based on the 6ES7155-6AU00-0HM0 foundation, this unit integrates enhanced durability features for harsh industrial operating conditions.
• It functions as a 2-port interface module designated as IM 155-6 PN R1, supporting up to 64 I/O modules per slot.
• The device enables R1 redundancy protocols, allowing for seamless failover mechanisms critical for high-review details automation processes.
• Multi-hot swap functionality permits module changes without system shutdown, maintaining operational continuity during maintenance windows.
• A cycle time of 0.25 ms is listed, providing rapid data processing speeds for real-time control applications.
• Optional PN strain relief accessories can be reviewed to enhance physical cable management and reduce mechanical stress on ports.

• The part number 6AG1155-6AU00-7HM0 uniquely identifies this specific variant within the broader SIPLUS product family structure.
• Normalization of the part number removes hyphens, resulting in the sequence 6AG11556AU007HM0 for database matching purposes.
• The lifecycle status is currently recorded as Active Product, indicating ongoing manufacturing and support review details.
• Product class B indicates review restrictions, requiring direct contact with documented Siemens representatives for handling procedures.

Parameters are factual source fields retained for model review.

• Physical dimensions are documented as 12.2 cm in width, 8.3 cm in height, and 6.3 cm in depth for spatial planning.
• The net weight is specified at 0.221 kg, which assists in calculating load requirements for mounting structures.
• Operating temperature range extends from -40 °C to +70 °C, facilitated by the applied conformal coating layer.
• The source category path places this item under Automation technology, specifically within the ET 200SP and SIPLUS interface modules sections.
• Conformal coating application is a key differentiator, providing protection against moisture, dust, and corrosive agents in demanding environments.

• Visual inspection should confirm the presence of dual PROFINET ports on the front panel for network connectivity.
• Check for labeling that clearly displays the full part number 6AG1155-6AU00-7HM0 for accurate inventory verification.
• Examine the housing integrity to ensure the conformal coating appears uniform and free from visible defects or cracks.
• Verify the slot configuration matches the description of supporting one BusAdapter slot for additional interface expansion capabilities.

• Review project documentation to confirm that the -40 to +70 °C temperature range meets environmental specifications.
• Assess whether R1 redundancy and multi-hot swap features align with the required system review details targets.
• Prepare details regarding the number of I/O modules needed to ensure the 64-module capacity is sufficient.
• Note the review restriction policy and prepare questions for Siemens review contacts regarding handling and disposal procedures.

• Ensure all technical parameters are cross-referenced with the latest Siemens product documentation before finalizing project designs.
• Contact Siemens review contacts directly to clarify the specific implications of the Class B review restriction policy.
• Verify that the optional PN strain relief components are included in the scope if mechanical stress is a concern.
• Maintain records of the normalized part number 6AG11556AU007HM0 for consistent tracking across inquiry preparation and engineering systems.
