Siemens 6AG1131-6BF00-7CA0 SIPLUS ET 200SP Digital Input Module

Part number

6AG1131-6BF00-7CA0

Brand

Siemens

Category

I/O Modules

Product type

I/O Modules

Lifecycle

Active Product

Dimensions

7.8 x 6.4 x 2.3 cm

Net weight

0.037 Kg

Source category

SIPLUS digital inputs

• Input voltage specification operates at 24 V DC for standard digital signal detection across all eight channels.
• Operating temperature range extends from -40 °C to +70 °C, ensuring functionality in extreme environmental conditions.
• Physical dimensions measure approximately 7.8 cm in length, 6.4 cm in width, and 2.3 cm in height for compact mounting.
• Net weight is recorded at 0.037 kg, facilitating easy handling and installation within dense control cabinet layouts.
• Channel diagnostics capability allows for monitoring individual input states, enhancing system visibility and fault detection accuracy.
• Color code CC01 identifies the specific variant configuration, aiding in visual verification during assembly and maintenance phases.

• Base hardware reference links to the 6ES7131-6BF00-0CA0 model, indicating the underlying platform architecture for this specialized variant.
• The SIPLUS designation signifies enhanced ruggedness compared to standard industrial components, tailored for severe operational environments.
• ET 200SP classification places this device within the scalable distributed I/O portfolio for modular automation strategies.
• Digital input module type confirms its primary function as a receiver for binary signals from field devices.
