6AV7860-1EX02-0AA1 SIMATIC Flat Panel USB-Link Transceiver

Part number

6AV7860-1EX02-0AA1

Brand

Siemens

Category

Industrial PCs

Product type

Industrial PCs

Lifecycle

Phase Out Announce

Dimensions

23.9 x 18.2 x 5.5 cm

Net weight

0.208 Kg

• Physical dimensions are listed as 23.9 centimeters in width, 18.2 centimeters in height, and 5.5 centimeters in depth for the housing structure.
• The net weight of the transceiver unit is documented at 0.208 kilograms, indicating a lightweight design listed for various mounting configurations.
• Functionality centers on USB-Link technology to bridge communication gaps between the flat panel interface and control systems via extended cabling setups.
• Application scope includes use cases requiring cable sets greater than five meters to maintain signal integrity and operational continuity in industrial environments.
• Lifecycle status is currently noted as Phase Out Announce, reflecting the manufacturer's current production stage classification for this specific part number.
• Brand attribution is confirmed as Siemens, aligning with the broader SIMATIC industrial automation portfolio and its associated technical standards.

• The part number 6AV7860-1EX02-0AA1 uniquely identifies this specific USB-Link transceiver variant within the Siemens SIMATIC Flat Panel accessory catalog.
• Normalization of the part number removes hyphens for database consistency, resulting in the identifier 6AV78601EX020AA1 for technical record keeping.
• Product classification falls under the Industrial PCs category, specifically addressing peripheral accessories rather than main processing units or controllers.
• Model designation confirms the item is an accessory component intended to enhance connectivity options for existing flat panel display installations.
