Siemens 6AG2232-4HD32-1XB0 Analog Output Module

Part number

6AG2232-4HD32-1XB0

Brand

Siemens

Category

PLC CPUs & Controllers

Product type

PLC CPUs & Controllers

Lifecycle

Active Product

Dimensions

10.6 x 9.00 x 5.6 cm

Net weight

0.19 Kg

Source category

SIPLUS extreme S7-1200 SM 1232 RAIL

• The device operates within a temperature range of -25°C to +60°C continuously. Keep dimensions 10.6 x 9.00 x 5.6 cm and net weight 0.19 Kg unchanged while comparing project documents and product image evidence.
• It includes overtemperature protection rated at ST1/2 for temperatures up to 70°C.
• The module supports a ten-minute duration at the elevated 70°C threshold safely.
• Four analog outputs deliver signals with a resolution of fourteen bits for voltage.
• Current output configurations maintain a thirteen-bit resolution for precision current control tasks.
• The physical dimensions measure 10.6 by 9.00 by 5.6 centimeters for mounting.

• Identify this unit as part of the SIPLUS extreme RAIL series lineup. Use the source path SIPLUS extreme RAIL analog modules / SIPLUS extreme S7-1200 SM 1232 RAIL to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• The specific model corresponds to the S7-1200 SM 1232 RAIL configuration type.
• Base functionality derives from the 6ES7232-4HD32-0XB0 reference design structure.
• Conformal coating application distinguishes this variant for extreme condition operational reliability.

Parameters are factual source fields retained for model review.

• Record the net weight of the module as 0.19 kilograms for logistics planning. Check product-owned images, label text, connector area, and submitted model references against the exact 6AG2232-4HD32-1XB0 record before publication.
• Verify the active product lifecycle status before initiating detailed engineering documentation reviews.
• Note the class B restriction which requires contacting a Siemens review contacts directly.
• Confirm the +/-10 V voltage range specification matches your control system needs.
• Check the 0-20 mA current range option against your actuator requirements.

• Ensure images display the front panel labeling clearly showing the part number. Review Siemens 6AG2232-4HD32-1XB0 as PLC CPUs & Controllers with source category SIPLUS extreme S7-1200 SM 1232 RAIL, recorded lifecycle Active Product, and submitted model identity.
