Siemens 6AG1055-1MA00-7BA2 SIPLUS LOGO! AM2 Expansion Module

Part number

6AG1055-1MA00-7BA2

Brand

Siemens

Category

PLC CPUs & Controllers

Product type

PLC CPUs & Controllers

Lifecycle

Active Product

Dimensions

9.5 x 7.00 x 5.5 cm

Net weight

0.133 Kg

Source category

SIPLUS LOGO! expansion modules

• Physical dimensions are listed as 9.5 x 7.00 x 5.5 centimeters for compact integration. Keep dimensions 9.5 x 7.00 x 5.5 cm and net weight 0.133 Kg unchanged while comparing project documents and product image evidence.
• Net weight is recorded at 0.133 kilograms for lightweight structural mounting.
• Power supply input accepts 12 or 24 volts direct current for standard operation.
• Two analog input channels provide signal processing for continuous measurement tasks.
• Input voltage range supports 0-10 volts for precise sensor interfacing requirements.
• Current loop capability includes 0/4-20 mA for industrial transmitter connections.

• The part number 6AG1055-1MA00-7BA2 identifies the specific SIPLUS LOGO! variant. Use the source path Automation technology / SIPLUS LOGO! / SIPLUS LOGO! expansion modules to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• Base model reference links to the 6ED1055-1MA00-0BA2 core hardware platform.
• Lifecycle status is documented as an active product for ongoing projects.
• Category classification places it under PLC CPUs and Controllers expansion units.

Parameters are factual source fields retained for model review.

• Temperature rating extends to -40 degrees Celsius for extreme cold environments. Check product-owned images, label text, connector area, and submitted model references against the exact 6AG1055-1MA00-7BA2 record before publication.
• Upper thermal limit reaches +70 degrees Celsius for high heat scenarios.
• Startup threshold allows initialization at temperatures as low as -25 degrees.
• Analog inputs support both voltage and current signal types simultaneously.
• Conformal coating provides additional environmental resistance against moisture and contaminants.

• Front view displays the connection terminals and status indicator lights clearly. Review Siemens 6AG1055-1MA00-7BA2 as PLC CPUs & Controllers with source category SIPLUS LOGO! expansion modules, recorded lifecycle Active Product, and submitted model identity.
• Side profile shows the compact form factor listed for DIN rail mounting.
• Label area confirms the full part number and Siemens branding identification.
• Rear section reveals the connector interface for linking to the main CPU.

• Verify the required analog input type before submitting the detailed inquiry. Keep dimensions 9.5 x 7.00 x 5.5 cm and net weight 0.133 Kg unchanged while comparing project documents and product image evidence.
• Confirm the ambient temperature conditions match the -40 to +70 range.
• Check power supply specifications to ensure 12 or 24 V DC alignment.
• Review project documentation for any specific conformal coating certification requirements.

• Ensure all technical parameters align with the specific application needs.
• Cross-reference the base model 6ED1055-1MA00-0BA2 for fundamental feature understanding.
• Document the environmental ratings for compliance with site safety standards.
• Submit inquiries with complete project details for accurate technical assessment.
