Siemens 6AG1055-1FB00-7BA2 SIPLUS LOGO! DM8 230V Expansion Module

Part number

6AG1055-1FB00-7BA2

Brand

Siemens

Category

PLC CPUs & Controllers

Product type

PLC CPUs & Controllers

Lifecycle

Active Product

Dimensions

9.5 x 7.00 x 5.5 cm

Net weight

0.169 Kg

Source category

SIPLUS LOGO! expansion modules

• Power supply input voltage is rated at 230 V AC for standard industrial electrical networks. Keep dimensions 9.5 x 7.00 x 5.5 cm and net weight 0.169 Kg unchanged while comparing project documents and product image evidence.
• Output type utilizes relay technology for four digital outputs, ensuring galvanic isolation.
• Conformal coating protects internal circuitry against moisture, dust, and corrosive atmospheric agents.
• Operating temperature range spans from -40 °C to +70 °C for extreme climates.
• Startup capability is maintained down to -25 °C, allowing cold environment initialization.
• Physical dimensions measure 9.5 cm in width, 7.00 cm in height, and 5.5 cm in depth.

• Base hardware reference links to the standard LOGO! 8 expansion module variant 6ED1055-1FB00-0BA2. Use the source path Automation technology / Controllers / SIPLUS LOGO! / SIPLUS LOGO! expansion modules to confirm catalog context, model family, parameter review scope, and technical inquiry preparation notes.
• The SIPLUS designation indicates specialized environmental hardening beyond standard industrial automation components.
• DM8 suffix denotes the specific device model within the broader LOGO! product family tree.
• Voltage rating 230V confirms application context with standard European and international mains power distributions.

Parameters are factual source fields retained for model review.

• Net weight is recorded at 0.169 Kg, indicating a lightweight design for DIN rail mounting. Check product-owned images, label text, connector area, and submitted model references against the exact 6AG1055-1FB00-7BA2 record before publication.
• Input count consists of four discrete digital channels for sensor or switch signal acquisition.
• Output count includes four discrete digital channels configured for relay switching mechanisms.
• Environmental class requires verification of specific site conditions against the -40 to +70 °C range.
• Mounting type is typically DIN rail, consistent with standard LOGO! expansion module installation practices.

• Label verification should confirm the full part number 6AG1055-1FB00-7BA2 is clearly printed.
• Terminal block orientation must match the wiring diagram for correct input and output connections.
• Conformal coating appearance should be uniform without visible cracks or peeling on the housing.
• LED indicator positions need checking to ensure proper status monitoring during operation cycles.

• Confirm the required quantity of units needed for the specific automation project scope.
• Verify the existing LOGO! CPU model supports expansion via the DM8 interface protocol.
• Check that the installation environment temperature stays within the specified -40 to +70 °C limits.
• Ensure the power supply network provides stable 230 V AC for correct module initialization.

• Source parameter review should validate the conformal coating specification against project environmental requirements.
• Technical documentation review must confirm the relay output characteristics match load switching needs.
• Dimensional check ensures physical fit within the control cabinet space allocated for expansion.
• Lifecycle status listed as Active Product indicates ongoing manufacturing support for this specific model.
